Honeywell CT47 (WWAN/WLAN)
Honeywell CT47 (WWAN/WLAN) - Image 2
Honeywell CT47 (WWAN/WLAN) - Image 3

Honeywell CT47 (WWAN/WLAN)

The CT47 is a robust mobile device crafted on the Mobility Edge™ platform, promising resilience, stability, and security for enterprises. Featuring the latest Qualcomm® QCM6490 processor and memory technology, it guarantees top-notch performance and support until Android 15. With cutting-edge 5G and Wi-Fi 6E connectivity, it ensures seamless communication indoors and outdoors, empowering workers in transportation, logistics, and warehouses with uninterrupted connectivity. Its ultra-durable build withstands drops up to 8 feet and 3500 tumbles, while the substantial 4775 mAh battery, coupled with Operational Intelligence analytics, ensures sustained productivity during demanding shifts. Additionally, it offers secure authentication options like fingerprint and facial recognition, safeguarding data and facilitating swift access for users.

Add to Enquiry
Download PDF
Specification
MECHANICAL
Dimensions (L x W x H): 170 mm x 79 mm x 19.2 mm (6.69 in x 3.11 in x 0.75 in)
Weight: 314g (11.1oz) with battery pack
Display Size: 13.97 cm (5.5 in)
Resolution: Full High-Definition (2160 x 1080)
Backlight: LED
Touchscreen: Rugged multi-touch capacitive touch panel, Glove, stylus and rain modes supported. Water droplet rejection with screen protector mode. Covered with Gorilla Glass 5 for increased resistance to drops
Hard Keys: Volume up/down key, left/right scan, power button, Push to Talk button
Audio: PTT, VoIP ready, speaker, HAC compliant, three microphones with noise cancellation
I/O Ports: Durable, flat IO connector, USB Type C connector. USB OTG supported via I/O ports. USB 3.1 is supported via USB Type C
SYSTEM ARCHITECTURE
Processor: Qualcomm QCS6490/ QCM6490 octa-core, 2.7GHz
Memory: 6GB DDR4x RAM, 128GB UFS Flash; 8GB DDR4x RAM, 128GB UFS Flash
Operating System: Each Android version guaranteed from Android 12 to 16
Storage Expansion: User-accessible microSD card up to 2 TB (SDXC/SDHC/ SDIO-compliant)
Rear Camera: 13-megapixel color camera
Front Camera: 8-megapixel color camera
SIM: Dual nano SIM; 1 eSIM and 1 nano SIM
Sensors: Ambient light sensor, Proximity sensor, Accelerometer, Gyroscope, Magnetometer, Barometer, eCompass, Hall sensor, High-G sensor
Battery: Li-Ion, 4775mAh standard; 4680mAh Wireless. Smart battery with integrated diagnostics tools
Charging Time: Quick Charge 3.0 compliant; Less than 3 hours to be fully charged
Operation Time:  14+ hours
Scan Engine: Honeywell FlexRange™ XLR, Honeywell S0703 (1D/2D barcode symbologies), Honeywell SDKs for Android, DPM supported via license
Application Software: Honeywell Mobility Edge Utilities and Demos
ENVIRONMENTAL
Operating Temperature: -20°C to +50°C (-4°F to +122°F)
Storage Temperature: -30°C to +70°C (-22°F to +158°F)
Humidity: 5% to 95% (non-condensing)
Drop: 3.0m (10ft) to concrete at room temperature per MIL-STD 810H booted. 2.4m (8 ft) to concrete at -20°C to 50°C (14°F to 122°F) per MIL-STD 810H booted; 2.4m (8ft) to concrete at room temperature per MIL-STD 810H, 1.8m (6ft) to concrete at -20°C to 50°C (14°F to 122°F) per MIL-STD 810H
Tumble: Exceeds 3500 0.5 m (1.64 ft) tumbles and 2000 1.0m (3.28 ft) tumbles per IEC 60068-2-32 specification
Environmental Sealing: Independently certified to meet IP65 and IP68 standards for moisture and particle intrusion
Electrostatic Discharge (ESD): ±15 kV Air and ±8 kV Direct
CONNECTIVITY
WIRELESS CONNECTIVITY (WWAN)
WWAN: Global band support, device certified with GCF-PTCRB, ATT, TMO, VZW
AT&T FirstNet Compliant
LTE Advanced Support
Up to 390 Mbps CAT13 LTE downlink
Up to 75 Mbps CAT5 LTE uplink
4G-LTE DL CAT18: ~1200 Mbps
4G-LTE UL CAT18: ~211 Mbps
5G NSA-DL: ~2400 Mbps, UL: ~1200 Mbps
5G SA-DL: ~2200 Mbps, UL: ~1000 Mbps
4G LTE: DL CAT18, ~1200 Mbps
4G LTE: UL CAT18, ~211 Mbps
5G FR1: Bands 1, 2, 3, 5, 7, 8, 12, 14, 20, 25, 28, 30, 38, 40, 41, 48, 66, 71, 77, 78, 79
LTE: Bands 1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19, 20, 25, 26, 28, 29, 30, 32, 38, 39, 40, 41, 42, 43, 48, 66, 71
UMTS/HSPA+ (3G): Bands 1, 2, 4, 5, 6, 8, 19
GSM: 850, 900, 1800, 1900 (Quad Bands)
4X4: Download MIMO supported on bands below:
5G: n7, n38, n41, n48, n77, n78, n79
4G: B7, B41, B42, B43, B48
PRIVATE NETWORK SUPPORT (WLAN)

WLAN: Wi-Fi certified; Wi-Fi 6E certified IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v/w/ mc/ax, 2×2 MU-MIMO;
Wi-Fi 6E (801.11ax); Dual Band Simultaneous(DBS); IPv4, IPv6
WLAN Security: OPEN, WEP, WPA/WPA2/ WPA3 (Personal and Enterprise)
Supported EAP: TLS, PEAP, TTLS, PWD, LEAP, CCX compatible
Bluetooth: V5.2 Bluetooth and BLE
2nd BLE: Available on all SKUs. Bluetooth profiles includes HFP, PBAP, A2DP, AVRCP, OPP, SPP, RATT

NFC: Integrated NFC reader, compliant with ISO/IEC 14443 A, ISO/IEC 14443 B, ISO/IEC 15693 (ICode), MIFARE 1K /
4K, MIFARE DESFire, Sony FeliCa, ISO/ IEC 18092 (Type F), Contactless payment support, P2P mode.
VPN: IPSec V4/L2TP, PPTP
Push to Talk (PTT): Supported
GPS Supported Protocols: GPS, GLONASS, Galileo, Beidou, NAVIC, QZSS. Dual-Band GNSS — concurrent L1/G1/ E1/B1 (GPS/QZSS, GLONASS, Galileo, BeiDou) + L5/E5a/B2a (GPS/QZSS, Galileo, BeiDou); a-GPS, Supports XTRA, SBAS.

Description

Powerful

  • Built on the newest generation of Mobility Edge™, a durable, stable and secure foundation for effective, long-lasting solutions.
  • Uses the latest Qualcomm® QCM 6490 processor and memory technology for high performance.
  • Guaranteed support through Android 15.

Reliable

  • Offers the latest 5G and Wi-Fi 6E technology to stay connected in various environments.
  • Reliable uptime and connection regardless in 5G, Wi-Fi 6E and CBRS networks.
  • Authentication technology means the CT47 keeps your data safe. Biometric login for simplified access and multiple-user logins are encrypted and stored locally.

Durable

  • The CT47’s ultra-rugged design allows it to withstand up to 8-foot drops and 3,500 real-world tumbles.
  • 4775-mAh battery helps keep the CT47 up and running throughout demanding shifts, while Operational Intelligence works to provide powerful analytics on device usage and battery health.
  • Certified dust- and water-protection matched with Gorilla Glass 5 FHD screen in a sleek form factor that can withstand the most rugged use cases and environments.
